R404 Refrigerant
Quality certified elements and wide product range
Description:
•For cold(0/+5 °C) and frozen(-18 °C) storage.
•Hermetic compressor and air-cooled condenser.
•Shipped compactly with the electrical panel and all control elements.
•Hot gas defrost system is available.
•Coolant is shipped as charged.
•Electrostatic painted steel galvanized cabinet.
In cold storage rooms, the internal volume is up to 34 m3 and In frozen storage rooms, the internal volume is up to 20 m3 (may vary depending on factors such as human circulation and outside temperatures.)
Monoblock cooling devices are very easy to install, but we still recommend that they be installed by professionals. In the part of the panel to be mounted, it is cut and placed in its place according to the guide in the package. Drainage holes are opened and hoses are passed through. Since the refrigerant is shipped with a gas charge, it does not require any gas charge from the outside. After the electrical connection is made, the device is ready for use.
| Compressor Brand | Embraco |
| Condenser Brand | KARYER |
| Fan Motor Brand | Ziehl-Abegg |
| Valve Brand | Danfoss |
| Production Facility | Turkey |
| Type of casing | Monoblock |
| Refrigerant | R290 |
| Compressor Brand | Embraco |
| Compressor Type | Hermetic Reciprocating |
| Condenser Brand | KARYER |
| Fan Motor Brand | Zıehl-Abegg |
| Rotation (RPM) | 4 Poles (~1.400 RPM) |
| Fan Motor (Quantity x Diameter) | 1×300 |
| Fan Motor Input Power (kW) | 1×0,113 |
| Fan Motor Power Sup. (V / Ph / Hz) | 220 – 230 / 1 / 50 |
| Valve Brand | Danfoss |
Case Dimensions:
| SERIE | Model | Power Supply (V/Ph/Hz) | Room / Ambient Temp. | HP | Cooling Cap. (W) | Power Consump. (W) | Volume (m3) | Casing Model |
| COLD SERIE | M008-K01.EK6181U.5 | 220-240/1/50 | +5/+32 °C | 1/3 | 695 | 312 | 5 | I |
| COLD SERIE | M011-K01.NE6210U.5 | 220-240/1/50 | +5/+32 °C | 3/8 | 922 | 378 | 8 | I |
| COLD SERIE | M018-K01.NE6214U.5 | 220-240/1/50 | +5/+32 °C | 1/2 | 1.143 | 474 | 12 | I |
| COLD SERIE | M023-K02.NT6220U.5 | 220-240/1/50 | +5/+32 °C | 3/4 | 1.443 | 675 | 14 | Il |
| COLD SERIE | M030-K02.NT6222U.5 | 220-240/1/50 | +5/+32 °C | 1 | 1.735 | 803 | 18 | Il |
| COLD SERIE | M036-K02.NT6224U.5 | 220-240/1/50 | +5/+32 °C | 1 | 1.920 | 880 | 21 | Il |
| COLD SERIE | M045-K02.NT6230U.5 | 220-240/1/50 | +5/+32 °C | 1 1/4 | 2.376 | 1.059 | 26 | Il |
| COLD SERIE | M060-K02.NJ9250U.4 | 380-420/3/50 | +5/+32 °C | 2 | 3.418 | 1.504 | 34 | Il |
| SERIE | Model | Power Supply (V/Ph/Hz) | Room / Ambient Temp. | HP | Cooling Cap. (W) | Power Consump. (W) | Volume (m3) | Casing Model |
| FROST SERIE | L006-K01.NE2155U.5 | 220-240/1/50 | -18/+32 °C | 3/4 | 573 | 370 | 3 | I |
| FROST SERIE | L008-K02.NE2168U.5 | 220-240/1/50 | -18/+32 °C | 3/4 | 689 | 463 | 5 | Il |
| FROST SERIE | L012-K02.NT2180U.5 | 220-240/1/50 | -18/+32 °C | 1 | 844 | 498 | 8 | Il |
| FROST SERIE | L015-K02.NT2210U.5 | 220-240/1/50 | -18/+32 °C | 1 1/4 | 1.041 | 602 | 10 | II |
| FROST SERIE | L026-K02.NJ2215U.4 | 380-420/3/50 | -18/+32°C | 2 | 1.464 | 1.099 | 20 | Il |
